Smart Home Alarm Systems 120 zones, LAN+ Z-wave (no 4G)

The VESTA-243 EasySmart Gateway Series is a compact and lightweight panel that incorporates F1 technology for an extended communication range, along with ZigBee or Z-Wave protocols for home automation. The updated gateway series now supports rechargeable battery packs, making it an ideal solution for security applications. In addition, the versatile VESTA-243 enhances home protection with 24-hour emergency monitoring and visual verification features. With optional built-in Wi-Fi connectivity, this gateway series offers cost-effective installation flexibility. Its ability to integrate ZigBee/Z-Wave repeaters helps expand the communication range, ensuring reliable coverage for large or complex premises.

Features

• Communications Path: IP (Ethernet and/or WiFI)
• Compatible with Climax’s F1 accessories
• Built-in Module Options: ZigBee, Z-Wave
• Two area configurations, supporting up to 160 zones
• Alarm event reporting via CID/SIA, Email, and SMS, Push notification via HPS Cloud Server
• Security Visual Verification and Real-time Monitoring/Reporting
• ZigBee and Z-Wave based home automation capabilities
• Energy Management capabilities
• 24/7 Environment Emergency Monitoring
• Three different arming modes
• Remote management of lights, thermostats, locks, home appliances via Smartphone App and PC Web browser
• Over-the-air firmware update capability

Specifications

• Communications protocol(s) ZigBee Pro HA 1.2 or Z-Wave 500
• Power supply 100-240V (50/60Hz), DC 9V/1A power adapter
• Rechargeable battery pack 600 mAH, AAA NiMH Battery Pack x 4 (for ESGW-15/18 models)
• Battery life 6 hours (for ESGW-15/18 models)
• Operating temperature -10°C to +45°C
• Operating humidity Up to 85% non-condensing
• Dimensions    114mm x 77mm x 33mm
• Compliance listings    CE 0681 (R&TTE Directive) / EN 300220-1&2 / EN300328 / EN301489-1&3&17 / EN 60950-1 / EN 62311
