Wireless alarmpanel 620 zones LAN+4G

The VESTA-047 is a multi-functional wireless alarmpanel with built-in SF1 (RF). It offers communication options through IP (Ethernet) & 4G, and you can optionally expand its functionality with Wi-Fi. With the panel, users can integrate compatible devices to automate their home, enhancing overall quality of life. It also includes key features such as emergency monitoring to protect your home from fire, flooding, and air toxins, as well as energy management to help reduce costs. This makes it easy to customize the VESTA-047’s services to suit your family’s needs, anytime and anywhere.

Features

• Communication Path: IP (Ethernet) + 4G
• OPTIONAL: RF, ZigBee, Z-Wave, LoRA
• OPTIONAL Expansion via USB Dongle
• Supports up to 620 Wireless Zones
• Alarm Event Reporting: CID/SIA
• Notifications: Email, SMS, and Push notifications via HPS Server
• Built-in Siren and Backup Battery
• Security Visual Verification: Real-time Monitoring & Reporting
• OPTIONAL: Home Automation: ZigBee and Z-Wave-based capabilities
• Energy Management Features
• 24/7 Emergency Environment Monitoring
• Remote Management: Control lights, thermostats, locks, and home appliances via Smartphone App and Web Browser
• Over-the-Air Firmware Updates
• Camera Compatibility: Supports IP cameras, PIR cameras, and PIR video cameras for visual verification and real-time monitoring
• Compliance: EN50131 Grade 2, Class II

Specifications

• OPTIONAL: ZigBee Protocol: ZigBee Pro HA 1.2, 2.4GHz
• OPTIONAL: Z-Wave Protocol: Z-Wave Plus 500 Series, 868.40MHz (EU) / 908.40MHz (US)
• OPTIONAL Add-on (VESTA-0478): External antenna (MMCX connector)
• OPTIONAL: Wi-Fi Module: 802.11 b/g/n
• Power Supply: 12V, 1A
• Backup Battery Options:
  • 7.2V, 600mAh Ni-MH rechargeable (for 3G/LTE option)
  • 7.2V, 1100mAh Ni-MH rechargeable (for 3G/LTE option)
• Backup Battery Life:
  • 14 hours (600mAh)
  • 28 hours (1100mAh)
• Operating Temperature: -10°C to 45°C (14°F to 113°F)
• Operating Humidity: Up to 85% non-condensing
• Dimensions: 150 mm x 140 mm x 42 mm
