Magnetic contact + input

Vesta-019N Series is a door contact designed to detect the unauthorized opening and closure of doors or windows. Vesta-019N is multi-functional, with a built-in extension terminal which allows it to be added to an existing wired sensor or to double as a universal transmitter.

Powered by a CR123 3V Lithium battery, Vesta-019N Series is particularly created to enhance operational efficiency, lower power consumption and reduce maintenance costs. Vesta-019N Series alerts the system control unit to any irregular activities and sends low battery signals as well as regular supervision signals to check system integrity.

Its elegant and modern design allows it to easily fit seamlessly into any home decor. Ideal for both residential and commercial installations and usage.

Features:

• Sleek, modern design with extended battery life

• Easily mounts on door or window frames

• Includes extension terminals for connecting wired devices

• Functions as a universal transmitter

• Integrates with home automation and security systems to control appliances

• Optional IPX4-rated waterproof case for outdoor use

• Strong magnet allows a maximum side-to-side gap of 28mm

• Randomized supervision signals ensure system integrity and aid troubleshooting

• Tamper protection to prevent unauthorized removal

• LED indicator for fault detection and test mode

• Low battery detection feature

• CE compliant

• Certified to EN 50131 Grade 2, Class II standard

Specifications:

• Power Source: 1 x 3V CR123 Lithium battery

• Battery Life: Up to 10 years

• Operating Temperature: -10°C to 45°C (14°F to 113°F)

• Operating Humidity: Up to 85% non-condensing

• Dimensions: 93.5 mm x 31 mm x 22.5 mm
