Wired-Wireless Converter

The VESTA-027 hardwire-to-wireless converter is engineered to transform existing wired security sensors into wireless zones, offering a seamless retrofit solution for traditional wired security systems. By converting wired sensors, the VESTA-027 helps save on installation costs, time, and materials—eliminating the need to replace wired devices with separate transmitters. This upgrade provides both homes and businesses with enhanced convenience and greater operational efficiency.

The VESTA-027 is capable of converting up to 9 wired zones into 9 wireless zones. The compact wireless module can be conveniently mounted near the security system’s control panel, ensuring easy installation and placement. It is compatible with 12V security sensors, including hardwired PIR motion sensors, door contacts, glass break sensors, and more, offering remarkable flexibility and scalability. The VESTA-027 is an excellent choice for upgrading existing hardwired systems or for use in new construction projects that incorporate hardwired security systems.

Features

• Converts 9 hardwired zones to wireless technology
• Compact and lightweight for easy installation
• Excellent stability with high sensitivity
• 4-pin terminal block for power supply
• 14-pin terminal block for 9 zones
• Tamper protection
• Converts existing hardwired PIR, door contacts, glassbreak sensors, and other 12V security sensors.
• Rechargable Backup Battery (HWC-1B only)
• LED Indicator
• Ideal for retrofitting existing wired security systems
• EN50131 Grade 2, Class II certified

Specifications

• Power Supply: 12V, 1A Power Adapter
• Backup Battery 750mAh, Ni-MH AAA batteries x8
• Backup Battery Life 72 hours
• Operating Temperature: -10°C to 45°C (14°F to 113°F)
• Operating Humidity: Up to 85% non-condensing
• Dimensions: 105mm x 163mm x 30mm
